| Transmitter Electrical Specifications |
| Tx DC Supply Current |
≤150mA |
| Tx_Data Differential Input Voltage |
300~2000 mV p-p |
| Receiver Electrical Specifications |
| Rx DC Supply Current |
≤125mA |
| Rx_Data Differential Output Voltage |
600~1900mV p-p |
| Rx_Data Output Rise / Fall Time |
150ps |
| Transmitter Optical Specification |
| Transmitter Type |
1310 nm F-P Burst Mode |
| Average Output Power (9/125 µ SMF) |
-1~4dBm |
| Optical Output with Tx OFF |
≤-45dBm |
| OMA Launch Power |
≥-0.22dBm |
| ≥-0.95mW |
| Optical Rise and Fall Time |
≤250ps |
| Tx Wavelength |
1310nm |
| Spectral Line Width |
≤2.5nm |
| Extinction Ratio |
≥9dB |
| Relative Intensity Noise |
≤-113dB/Hz |
| Optical Return Loss |
≤15dB |
| Total Jitter |
≤0.2UI |
| Optical Cross Talk |
40dB |
| Transmit Reflectance |
≤-12dB |
| Receiver Optical Specifications |
| Receiver Type |
1490 nm P-I-N/TIA CW Mode |
| Optical Signal Indicator |
Signal Detect |
| Wavelength |
1490nm |
| Received Optical Power |
-26~-3dBdBm |
| Maximum Input Optical Power |
≤4dBm |
| OMA Receiver Sensitivity |
≤-23.2dBm |
| Receiver Reflectance |
≤5µW |
| ≤-12dB |
| Stressed Receiver Sensitivity |
≤-22.1dBm |
| OMA Stressed Receiver Sensitivity |
≤-21.3dBm |
| ≤7.4µW |
| Vertical Eye Closure Penalty |
≥1.5dB |
| Rx_SD Assert |
-42~-26dBm |
| Rx_SD Deassert |
-42~-26dBm |
| Rx_SD Hysteresis |
≥0.5dB |
